Enter the proper CLI commands and analysis the outputs on the Cisco routers to answer the multiple choice questions
From the network topology diagram, click on the router icon to gain access to the console ofthe router
No console or enable passwords are required
There are four multiple-choice questions with this task. Be sure to answer all four questions before selecting the Next button
Not all the CLI commands or commands options are supported or required for this simulation.
All the devices in this simulation have been pre-configured and you are not required to enter in any configurations.
CE7#
RP/0/RSP0/CPU0:PE7#
On CE 7 router, which statement is correct regarding the "QOS-POLICY policy map configurations?
| A. |
Traffic matched bythe"QOS-HTTP-1" class-map is shaped to an average is rate of 2560000 128000bps | |
| B. |
Traffic matched bythe"QOS1-HTTP-2" class-map will be queued in the low-latency-queue which has a maximum bandwidth guarantee of 64000 | |
| C. |
Traffic matched by the "QOS-FTP-1" class-map can't use more than 256 Kbps under any condition | |
| D. |
The "QOS-POLICY is applied to the gi0/0 interface in the input direction |
# show policy-map
# show policy-map interface x/y
# show running-config policy-map
